Dynamic DX Installation Manual

No. 60027, Issue 4. January 1998
8 Diagnostics51
DX System
Status LED
Flash Code
SLM Status
LED Flash
Code
Likely Cause of Fault and Possible Action
2 3
Steering Fault
Cause: The Position Sense Pot is faulty or cannot
track the requested steering position.
Action: < Check the Pot Shaft is not slipping, or the
Pot. Body turning.
< Check the Pot For short and open circuits
between pins.
< Ensure that the clutch is engaged and not
slipping.
< Ensure that there is no excessive load on
the steering system.
< Check the servo motor connector and
wiring.
Note: If this problem only occurs when large
steering movements are requested, the SLM`s motor
speed parameter may need to be recalibrated using
an HHP.
2 4
Lighting Fault
Cause: 1. A fault is detected in the lighting circuits
or the internal regulator (if fitted).
2. Indicator lights are flashing faster than
Action: < Check the lighting circuitry for shorts and
open circuits.
< Check side and indicator bulbs.
5
Clutch Released
Cause: The clutch switch is or has been in the
released position.
Action: < Re-engage the clutch if necessary and turn
the DX System off then on.
< Check the servo motor connector and
wiring.
< Check the operation of the clutch switch.
