No. 60027, Issue 4. January 1998
8 Diagnostics53
DX System
Status LED
Flash Code
SLM Status
LED Flash
Code
Likely Cause of Fault and Possible Action
10 10
CANH Fault
Cause: 1. An invalid voltage has been detected on
the DXBUS CANH line.
2. Communication is not possible using the
CANH wire.
3. Hazard lights were turned on when the
DX System was turned on.
Action: < Check the continuity of the DXBUS cable.
< Check for shorts between DXBUS pins.
An open or short circuit on another DX
module can cause this fault.
< If the Hazard Lights were already
switched on when the DX System was
turned on, Flash Code 10 and Limp Mode
(slow driving) may result.
To clear this fault, turn the Hazard Lights
off, then turn the DX System off then on
again.
11 11
Stall Timeout Fault
Cause: The servo motor current has been at or close
to current limit for longer than the Stall
Timeout parameter value.
Action: < Turn the DX System off then on again.
To Next Page
