1. Clip in the spacer ring (2) on the recoil starter (1).
2.
NOTICE!
The recoil starter may get damaged!
– Do not mix up the fastening screws for
the recoil starter by mistake.
Assemble the recoil starter.
3. Attach the guide handle and tighten the right hand fastening
screws hand-tight.
Concluding work
Fig. 72
Fig. 73
1 Pipe clamp
2 Fastening screw M6x18
3 Fastening screw M6x14
4 Fastening screw M6x18
Fig. 74
Maintenance – Annually
DR6X
80
