BATTERY OPERATION
DYNATRON SOLARIS
®
PLUS SERIES | SERVICE MANUAL REV. 6 | AUGUST 29, 2017 135
e treatment intensity will ramp down, any treatments that were running at the time will stop, and the device will
shut down. Before battery operation can continue, the battery must be recharged.
Battery Requirements
• 12 volt and at least 5 amps hours.
• Battery adaptor cord must match the plug end of the battery pack. e barrel plug end must match the 0.325” barrel
jack adaptor plug on the Solaris.
• e cord needs to be a minimum of 18 AWG gauge wire. 14-16 AWG gauge wire will work as well with a 5 amp fast
blow fuse.
Battery Life
e length of time that a unit can be used with a battery pack is dependent on several factors:
• e amperage of the battery pack. Larger amperage will provide longer use.
• e modality used. Light erapy treatments require more power than Ultrasound or Stim modalities while
Ultrasound requires more power than Stim modalities.
• e intensity of the treatments. e higher the intensity, the higher the consumption of power.
• e use of multiple treatments. e more channels used, the more power is consumed.
• e amount of charge remaining on the battery.
As a general rule, the unit may be run continuously for 30 minutes to several hours depending on these factors.
Note: If using a smaller gauge wire (20 AWG and up) the BATT LOW error is possible when the battery is not low.
CAUTION
When a battery is employed to operate the Solaris Plus unit, do not use Ultrasound, Tri-Wave light pads/probes, or
the ermoStim probe. ese accessories will deplete the battery rapidly.
CAUTION
When disposing of a used battery, follow manufacture’s guidelines and comply with the laws and procedures required
in your area.
