EMS Operation
SkyView SE Pilot’s User Guide - Revision I 5-5
When OIL TEMP < 190° F, the OIL TEMP gauge displays these ranges:
• 100-120 and 230-266° F in YELLOW
• 120-190° F in GREEN if OIL TEMP has been above 190° F “more recently” than OIL TEMP was
below 120° F; otherwise 120-190° F is displayed in BLACK OUTLINED IN WHITE
• 190-230° F in GREEN
• 266-280° F in RED.
When OIL TEMP is > 190° F, the OIL TEMP gauge will display different ranges:
• 100-120 and 230-266° F in YELLOW
• 120-230° F in GREEN
• 266-280° F in RED
• The alarm type for oil temperature is the “self-clearing” type.
912 iS / 915 iS Temperature Caution
The default Van’s RV-12 configuration includes a parameter that enables detection of high
coolant temperature. The default behavior is if the coolant temperature exceeds 220 degrees F
and tachometer is <2500 RPM, a caution message will appear (TEMP HIGH – INCR RPM) to
encourage the pilot provide more cooling.
912 iS / 915 iS Power/Eco mode and Throttle Position
The POWR/ECO widget will turn green and display “ECO mode” when the engine is running
economically. In this mode you will experience reduced fuel consumption.
• When the engine is off, the THRTL widget will show a green range to assist cold-start
scenarios. Note that both lane switches and start power must be on in order to display the
throttle position widget.
See your Rotax manual for more information.
915 iS Boost/Static Pressure and Wastegate Duty Cycle Percentage
The BOOST and STATIC widgets are available for manifold pressure monitoring on 915iS
engines. Additionally, an optional WSTGT counter is available for wastegate duty cycle
monitoring on 915 iS engines.
ULPower 520T Behavior
520T Boost/Static Pressure
The BOOST and STATIC widgets are available for manifold pressure monitoring on 520T engines.
