E Instruments BTU900 - Replacing the Battery Pack

60
K800000000EJ 020650A0 170512
6.8 Replacing the battery pack
Follow these instructions to replace the battery pack:
1
Undo the screw on the battery
compartment cover and remove it .
2
Remove the battery pack.
Battery pack connector
3
Remove the battery pack connector, and replace the pack with a new one following the reverse procedure
described above.
