2.0 TECHNICAL SPECIFICATIONS
2.1 Technical Specifications
Autozero: Manual autozero cycle (without probe inserted in the stack).
Self-diagnosis: All the functions and internal functions are checked and anomalies signalled.
Type of Fuels/Oils: 7 predefined by the factory and 16 that can be programmed by the user.
Power: Li-Ion battery pack with internal protection circuit.
Battery charger: External battery charger.
Battery autonomy: 12 hours of continuous operation from fully charged battery.
Charging time: 4 hours for charging from 0% to 90% (5 hours for 100% charge).
Internal data memory: 300 complete data analysis, time and name of the customer can be stored.
User data: 3 programmable user names.
Print-out heading: 4 lines x 24 characters, customisable by the user.
Display: Graphic backlit LCD, measuring 42 x 60 mm.
Communication port: USB with mini-USB connector.
IR interface for external printer using HP-IR protocol (optional).
Bluetooth (optional): Communication range: <100 meters (free field)
Manufacturer: FREE2MOVE
Model: F2M03GLA - CLASS 1
Bluetooth SIG Qualification Design (QDL) Certificate: B012541
Certification EC-R & TTE: 0681
Line filter: With replaceable cartridge, 99% efficient with 20um particles.
Suction pump: 1.2 l/min heads at the flue up to 135hPa.
Condensate trap: Outside the instrument.
Carbon black: Using an optional external Smoke hand pump; it is possible to simply enter and
print the Smoke index results.
Condensing boiler efficiency: Automatic recognition of the condensing boiler, with calculation and printout of
efficiency (>100%) on the LHV (Lower Heating Value) in accordance with
UNI10389-1.
Environmental gases: Measurement and separate printout of the ambient CO and NO values.
Draft test: Draft tested as per the UNI 10845 standard. Using the external draft gauge
AACDP02 the resolution is 0.1 Pa with 0.5 Pa accuracy.
Operating temperature range: -5°C to +45°C (23°F to 113°F)
Storage temperature range: -20°C to +50°C (-4°F to 122°F)
Operating humidity range: 20% to 80% RH
Protection grade: IP42
Air pressure: Atmospheric
Outer dimensions: Analyzer: 220 x 100 x 52 mm (H x W x D)
8.6 x 3.9 x 2 inches (H x W x D)
Case: 225 x 109 x 69.5 mm (H x W x D)
8.8 x 4.3 x 2.7 inches (H x W x D)
Weight: Analyzer: ~ 19.4 oz
Compliant with the CEI-EN 50379-2 European Standard.
External IR printer (optional):
•
With thermal paper, 24 characters, data transmission through IR interface and HPir standard protocol.
•
Paper roll size: 58mm x 40mm (paper length 25 meters, about 120 report tickets).
•
Power supply: with internal rechargeable Ni-MH batteries.
•
External battery charger prov.ided with printer.
