IMPORTANT
The fiber optic cable must be laid straight, without twisting. It must not be uncoiled from the top
of the spool. And it is important to prevent it from tangling with other cables and hoses in the
drag chains.
3. Connect the fiber to the laser head.
1. Remove the connections on the laser head.
Remove the green signal line on the left, and remove the signal box if there is no room for tools.
Remove the water hoses on the right, and remove the gas pipe.
Remove the servo cables on the top.
