CV3100 series and MINI series high performance general purpose inverter instruction manual
2-4
Sensorless
vector
control
150% output of torque at 1Hz, rev accuracy: 0.1%
Motor parameters
automatic read
Reading the parameters from motor when completely stop in
order to achieve optimal controlling effect.
Setting of operating manual; setting of control terminal;
setting of serial port; switching by three ways.
Frequency setting
passage
Setting of keyboard analog potentiometer; setting of keyboard
▲
▲, ▼ keys; setting of functional code digits; setting of serial
port, setting of terminal UP/DOWN, setting of analog voltage,
setting of analog current ; setting of impulse, setting of
combination; switching at any time by kinds of setting ways.
Forward/reverse rotating command, 6-way programmable
switching value input to set 30 functions.
2-way analog signal input, 0～20mA, 0～10V optional.
Analog signal output 0～10V 、0~20mA to get output of
physical quantity like frequency and output frequency
3-way programmable open collector output; 1-way relay
output signal; can output different physical quantities.
Display setting frequency, output voltage, and output current
and so on.
Display external
instrument
Display output frequency, output current, and output voltage
and so on.
Over current protection, over voltage protection, under voltage
protection, over heat protection, over load protection.
Braking unit, remote operating panel, remote cable, soleplate
of keyboard.
Indoors, not suffer from sun, dust, corrosive gas, oil fog, and
steam and so on.
Shorter than 1000m (derating at higher than 1000m)
Less than 90%RH，no condensation
IP20 (In service state or keyboard state.)
