CV3100 series and MINI series high performance general purpose inverter instruction manual
4-1
Chapter 4 Running and Operating
4.1 Running of inverter
4.1.1 Running order channels
CV3100 inverter has 3 kinds of order channels for controlling running operation
such as start, stop, jog, etc.
Operation Panel
Control by keys , , on keyboard to start or stop the motor.
Control terminal
Use control terminal FWD, REV, COM to make double-line control, or use one
of the terminals of DI1~DI6 and two terminals FWD and REV to make 3-line
control
Serial Port
Control start or stop of the inverter through upper machine or other devices which
can communicate with the inverter.
Choose order channel by setting function code P0.04
4.1.2 Frequency-provision channels
Under common running mode, CV3100 series inverter has 9 kinds of provision
channels:
0: keyboard analog potentiometer provision
1: Digital setting 1 keyboard ,provision
2: Digital setting 2 terminal UP/DOWN provision
3: Digital setting 3, serial port provision
4: Analog voltage signal AI1 (0-10V) provision
5: Analog current signal AI2 (0-20mA) provision
6: Terminal pulse (0-10KHz) provision
7: Compounding setting
8: External terminal selection
