EasyDrive MINI-L-2S0015M - Specifications

CV3100 series and MINI series high performance general purpose inverter instruction manual
2-3
2.2 Specifications
Item
Specifications
Input
Rated voltage and
frequency
Single-phase 220V, three-phase 220V,
three-phase 380V; 50Hz/60Hz
Grid range
Voltage: -20% ～ +20％
Output
Rated voltage
0～220V /0～380V
Frequency range
0Hz～400Hz
Overload capability
M:150% for 1 min, 180% for 1s, 200% instant protection
FP: 120% for 1 min, 150% for 1s, 180% instant protection
Main control
functio
Modulation mode
Space voltage vector PWM control ;
Control mode
Sensorless vector control (SVC)
Frequency accuracy
Digital setting: Max frequency ×±0. 01%
Analog setting: Max frequency ×±0. 2%
Frequency resolution
Digital setting: 0.01Hz；
Analog setting: Max frequency ×0.1%
Starting Frequency
0.0Hz~10.00 Hz
Torque rise
Auto torque rise, manual torque rise 1%～30.0%(valid for
V/F)
V/F curve
Three ways：Linear V/F curve, square V/F curve, user
self-defining V/F curve
Acceleration/
deceleration time
Optional time unit (Min/s), the longest: 3600s (settable in the
range of 0.1～3600s).
DC braking
Be optional during both starting and stopping, the operating
frequency: 0～20Hz，operating time: settable within 0～30s
Jogging
Jogging frequency range: 0.1Hz～50.00Hz,
jogging acceleration and deceleration time: 0.1～3600s.
Built-in PID
It is convenient for forming closed loop control system,
applicable for course control like pressure and flow, etc.
Multi-speed operating
Realize multi-speed running by built-in PLC or control terminal.
Weaving wobble
frequency
Can get wobble frequency of adjustable central frequency
Auto voltage adjustment
When main voltage changes, the output voltage may be kept
constant by adjusting PWM output (AVR function).
Auto energy-saving
running
According to load condition, V/F curve can be optimized
automatically to get the aim of energy-saving running.
Auto current limiting
Limit in-service current automatically, so as to avoid tripping for
fault caused by frequent over current.
