EasyDrive MINI-L-2S0015M - Analog Input;Output Parameter （P5.00－P5.16

CV3100 series and MINI series high performance general purpose inverter instruction manual
5-9
Analog Input and Output Parameter
Function
Code
Name &
Definition
Set Range
Minimun
Unit
Factory
Default
Communi
cation
Address
Modify
P5.00
AI1 input
voltage of
lower limit
0.0～【P5.01】
0.1V
0.0V
0500H
○
P5.01
AI 1input
voltage of
upper limit
【P5.00】～10.0V
0.1V
10.0V
0501H
○
P5.02
AI2 input
current of
lower limit
0.0～【P5.03】
0.1mA
0.0mA
0502H
○
P5.03
AI2 input
current of
upper limit
【P5.02】～20.0mA
0.1mA
20.0mA
0503H
○
P5.04
Pulse input
frequency of
lower limit
0.0～【P5.05】
0.1KHz
0.0KHz
0504H
○
P5.05
Pulse input
frequency of
upper limit
【P5.04】～20.0kHz
0.1KHz
10.0KHz
0505H
○
P5.06
Setting
frequency to
minimum
input
0.0Hz～upper frequency
0.01Hz
0.00Hz
0506H
○
P5.07
Setting
frequency to
maximum
input
0.0Hz～upper frequency
0.01Hz
50.00Hz
0507H
○
P5.08
Delayed time
to analog
input signal
0.1～5.0s
0.1s
0.5s
0508H
○
P5.09
AO1
multi-function
al analog
output
terminal
function
selection
0：Output frequency
1：Setting frequency
2：Output current
3：Motor rev.
4：Output voltage
5：Bus voltage
6：PIDration
7：PID feedback
1
0
0509H
○
P5.10
DO3
multi-function
al pulse output
terminal
function
selection
1
2
050AH
○
