EasyDrive MINI-L-2S0015M - Motor and Vector Control Parameter （ P1.00－P1.15

CV3100 series and MINI series high performance general purpose inverter instruction manual
5-3
Motor and Vector control Parameter
Function
Code
Name &
Definition
Set Range
Minimun
Unit
Factory
Default
Communi
cation
Address
Modify
P1.00
Motorrated
voltage
380V：200～500V
220V：100～250V
1V
380V
220V
0100H
○
P1.01
Motor rated
current
0.1～600.0A
0.1A
0101H
○
P1.02
Motor rated
rev.
300～3000RPM
1RPM
0102H
×
P1.03
Motor rated
freq.
1.00～400.00Hz
0.01Hz
50.00Hz
0103H
×
P1.04
Motor
no-loading
current
0.1～500.0A
0.1A
0104H
○
P1.05
Motor stator
resistance
0.001～10.000Ω
0.001
0105H
×
P1.06
Motor rotor
resistance
0.001～10.000Ω
0.001
0106H
×
P1.07
Motor
inductance
0.01～600.00mH
0.01mH
0107H
×
P1.08
Motor mutual
inductance
0.01～600.00mH
0.01mH
0108H
×
P1.09
Reserved
P1.10
Rotation
deviation
compensation
0.50-2.00
0.01
1.00
010AH
○
P1.11
Pre-excitation
of-motor
selection
0：conditionally available
1：available all along
1
0
010BH
×
P1.12
Pre-excitation
continuing
time
0.1～10S
0.1
0.2S
010CH
×
P1.13
Motor auto
tuning
0：no action
1：statictuning
(available P0.00=0)
1
0
010DH
×
P1.14
Auto speed
regulation
(ASR)
proportion (P)
gain
0.01～5.00
0.01
1.00
010EH
○
P1.15
ASR
integration (I)
time constant
0.01～10.00S
0.01s
2.00S
010FH
○
