EasyDrive MINI-L-2S0015M - Outline of Inverter; Outline Size

CV3100 series and MINI series high performance general purpose inverter instruction manual
2-5
2.3 Outline of inverter
Remote-control
keyboard
Control panel
Multi-function
terminal
Maincircuit terminal
Entrance of
Control cable
Mounting hole
of soleplate
Connection of
operating panel
Fixed hole of upper cap
Upper cap plate
Mounting hole of
soleplate
Power supply
inputcap
Inversion output
Vent hole
Mounting hole
of soleplate
2.4 Outline size
MINI series
（MINI-S） （MINI-L）
(unit : mm)
W
W1
H
H1
H2
D
D1
D2
D3
R
MINI-S
85
74
155
144
122
72
98
112
2.5
MINI-L
98
88
175
165
152
142
80
3
