EasyDrive MINI-L-2S0015M - Digital Input;Output Parameter （ P4.00－P4.16

CV3100 series and MINI series high performance general purpose inverter instruction manual
5-7
Function
Code
Name &
Definition
Set Range
Minimun
Unit
Factory
Default
Communi
cation
Address
Modify
P3.08
Software
edition
0～99.99
0.01
0308H
×
P3.09
Accel. &
Decel. time
unit
0：Second
1：Minute
1
0
0309H
○
Digital Input and Output Parameter
P4.00
Input terminal
DI1 function
0：Leave control terminal
unused
1： Multi-step speed definition 1
2： Multi-step speed definition 2
3： Multi-step speed definition 3
4：Accel. & Decel. 1
5：Accel. & Decel. 2
6：Freq. channel selection 1
7：Freq. channel selection 2
8：Freq. channel selection 3
9：Forward jog control
10：Reverse jog control
11：Inverter running forbidden
command
12：Freq. increasing command
13：Freq. decreasing command
14：Peripheral failure input
15：Three-line operation control
16：DC braking command
17：Counter reset signal input
18：Counter trigger signal input
（Available to DI6）
19：Exterior pulse input
（Available to DI6）
20：Exterior reset signal input
21：UP/DOWN terminal
frequency reset
22：PID operation available
23：Programmable multi-step
speed running available
24：Wobbling frequency
operation available selection
25：Wobbling freq. status reset
26：Exterior stop command
27：Free stop control
28：Reserve
29：Command channel input
switched to terminal
30：Freq. input channel switched
to AI2
31：Timer start
32：Timer reset
1
0
0400H
×
P4.01
Input terminal
DI2 function
1
0
0401H
×
P4.02
Input terminal
DI3 function
1
0
0402H
×
P4.03
Input terminal
DI4 function
1
0
0403H
×
P4.04
Input terminal
DI5 function
1
0
0404H
×
P4.05
Input terminal
DI6 function
1
0
0405H
×
