CV3100 series and MINI series high performance general purpose inverter instruction manual
5-8
Function
Code
Name &
Definition
Set Range
Minimun
Unit
Factory
Default
Communi
cation
Address
Modify
P4.06
FWD/REV
terminal
control
method
0: Two-line control mode 1
1: Two-line control mode 2
2: Three-line control mode 1
3: Three-line control mode 2
(reserved)
1
0
0406H
×
P4.07
Open
collector
terminal DO1
output
0: Inverter running indication
1: Freq./speed arrival signal
（FAR）
2: Freq./speed detecting signal
(FDT)
3: Inverter zero speed running
indication
4: Peripheral failure stop
5: Output freq. arriving at the
upper limit
6: Output freq. arriving at the
lower limit
7: Programmable multi-step
speed circular running finished
8: Inverter overload alarming
signal
9: Inverter starts to run in train
10:Counter checkout signal
output
11:Counter reset signal output
12: Inverter failure
13:less-voltage stopping
14: Wobbling frequency
fluctuationlimit
15: Programmable multi-step
speed running finished.
16: Reserved
17: Timing to output
1
0
0407H
○
P4.08
Open
collector
terminal DO2
output
1
1
0408H
○
P4.09
Programmabl
e relay output
1
12
0409H
○
P4.10
FDT level
setting
0.00Hz～Upper limit frequency
0.01Hz
10.00Hz
040AH
○
P4.11
FDT lag value
0.0～30.00Hz
0.1Hz
1.00Hz
040BH
○
P4.12
Freq. arrival
FAR checkout
width
0.00Hz～15.0Hz
0.01Hz
5.00Hz
040CH
○
P4.13
Overload
pre-alarm
checkout level
20～120％
1%
100％
040DH
○
P4.14
Overload
pre-alarm
delayed time
0.0～15.0s
0.1s
1.0s
040EH
×
P4.15
Counter reset
value
【P4.16】～60000
1
1
040FH
×
P4.16
Counter
checkout
value
0～【P4.15】
1
1
0410H
×
