EasyDrive MINI-L-2S0015M - Communication Parameter （P8.00－P8.04

CV3100 series and MINI series high performance general purpose inverter instruction manual
5-15
Communication Parameter
Function
Code
Name &
Definition
Set Range
Minimun
Unit
Factory
Default
Communi
cation
Address
Modify
P8.00
Local
communica
tion
address
0：Host station
1～31: Ancillary station
1
1
0800H
×
P8.01
Communic
ation
scheme
LED single digit：Baud rate
selection
1：2400BPS
2：4800BPS 3：9600BPS
4：19200BPS 5：38400BPS
LED tens digit：Data form
0：No checkout
1：Even checkout
2：Odd checkout
LED hundreds digit：Reserved
LED thousands digit：
0：return information when modify
data
1：no return information when
modify data
1
013
0801H
×
P8.02
Communic
ating
overtime
checkout
time
0.0～100.0s
0.1s
10.0s
0802H
×
P8.03
Response
delay
0～1000ms
1ms
5ms
0803H
×
P8.04
Linkage
proportion
setting
0.01～10.00
0.01
1.00
0804H
○
Protection Function
P9.00
Motor
overload
stall
prevention
factor
30％～110％
1%
105%
0900H
○
P9.01
Low
voltage
prevention
level
360～480V(380V machine type)
1V
400V
0901H
○
P9.02
Over
voltage
prevention
level
660～760V(380v machine type)
1V
700V
0902H
○
P9.03
Over
current stall
prevention
level
80％～220％
1%
180％
0903H
○
