CV3100 series and MINI series high performance general purpose inverter instruction manual
5-2
Function
Code
Name &
Definition
Set Range
Minimun
Unit
Factory
Default
Commu
nication
Address
Modify
P0.07
Lower limit
frequency
0.00～【P0.06】
0.01Hz
00.00Hz
0007H
×
P0.08
Basic running
frequency
1.00～Upper limit frequency
0.01Hz
50.00Hz
0008H
×
P0.09
Max.output
voltage
200～500V
100～250V
1
380V
220V
0009H
×
P0.10
Model choose
0：G type（Constant torque load）
1：FP type（Fan, pump load）
1
0
000AH
×
P0.11
Torsion rising
selection
0：Manual
1：Automatic
1
0
000BH
×
P0.12
Torsion rising
setting
0.0～30.0％
Note: available when F0.11=0
0.1
000CH
○
P0.13
Rotation
deviation
frequency
compensation
0.0～150.0％
0.1
0.0
000DH
○
P0.14
Acceleration
time 1
0.1～3600S
Accel&Decel time unit reference
P3.09)
0.1
000EH
○
P0.15
Deceleration
time 1
0.1
000FH
○
P0.16
V/F curve
setting
0：constant torsion curve
1：decreasing torsion curve 1
（1.7 hypo-power）
2：decreasing torsion curve 2
（2.0 hype-power）
3：Customer self-defined V/F
curve mode（determined by
P0.17～P0.22）
1
0
0010H
×
P0.17
V/F freq.
value F1
0.00～frequency value F2
0.01Hz
12.50Hz
0011H
×
P0.18
V/F volt.
value V1
0.0～voltage value V2
0.1%
25.0％
0012H
×
P0.19
V/F freq.
value F2
Freq. value F1～Freq. value F3
0.01Hz
25.00Hz
0013H
×
P0.20
V/F volt.
value V2
Volt. value V1～Volt. value V3
0.1%
50.0％
0014H
×
P0.21
V/F freq.
value F3
Freq. value F2～basic running
frequency
0.01Hz
37.50Hz
0015H
×
P0.22
V/F volt.
Value V3
Voltage value V2～100.0％
0.1%
75.0％
0016H
×
P0.23
REV/JOG
function
selection
0：REV
1：JOG
1
1
0017H
○
