EasyDrive MINI-L-2S0015M - Page 60

CV3100 series and MINI series high performance general purpose inverter instruction manual
5-10
Function
Code
Name &
Definition
Set Range
Minimun
Unit
Factory
Default
Communi
cation
Address
Modify
P5.11
AO1 gain
setting
20～200%
1%
100％
050BH
○
P5.12
Reserved
050CH
P5.13
DO3 gain
setting
20～200%(Rating 10KHZ)
1%
100％
050DH
○
P5.14
Reserved
050EH
P5.15
Compounding
specified
channel
setting
LED single digit:Operand 1
0：Keypadpotentiometer;
1：Digit setting
2：reserved
3：Communication setting
4：AI1 5：AI2
6: Terminal pulse.
LED tens digit：Operand 2
0：Keypadpotentiometer
1：Digit setting
2：reserved
3：Communication setting
4：AI1 5：AI2
6：Terminal pulse
LED Hundreds digit：Operand
3
0：Keypadpotentiometer
1：Digit setting 2：reserved
3：Communication setting
4：AI1 5：AI2
6：Terminal pulse
LED Thousands digit:
Reserved
1
000
050FH
×
P5.16
Compounding
specified
arithmetic
setting
LED single digit：Arithmetic 1
0：Addition 1：Subtraction
2：Absolute value（Subtraction）
3：Choose Maximum.
4：Choose Minimum.
LED tens digit：Arithmetic 2
0：Addition 1：Subtraction
2：Absolute value（Subtraction）
3：Choose Maximum.
4：Choose Minimum.
5：Operand 3 not be concerned
with operation
LED Hundreds & thousands
digit: Reserved
1
00
0510H
○
