CV3100 series and MINI series high performance general purpose inverter instruction manual
2-13
Table 2-4 Selectable table of braking resistor
Applicable motor
Power（KW）
NOTE:
1. The standard product has built-in braking unit without braking resistor, if need
braking resistor, user shall order from us separately and indicate clearly when
ordering.
2. The device of 18.5KW and above need to be connected with braking resistor and
unit outside. (If demands for them please inquire manufacturer).
3. Wiring of braking resistor should be less than 5m;The braking resistor would
have temperature rise due to feedback energy consumption during dynamic
braking, please ensure the safety protection and good ventilation.
