EasyDrive MINI-L-2S0015M - Page 63

CV3100 series and MINI series high performance general purpose inverter instruction manual
5-13
Function
Code
Name &
Definition
Set Range
Minimun
Unit
Factory
Default
Communic
ation
Address
Modify
P7.05
Stage 5
running
time
0.0～6000.0s
0.1s
10.0s
0705H
○
P7.06
Stage 6
running
time
0.0～6000.0s
0.1s
10.0s
0706H
○
P7.07
Stage 7
running
time
0.0～6000.0s
0.1s
10.0s
0707H
○
P7.08
Reserved
P7.09
Multi-step
speed
running
direction 1
LED single digit：Stage 1
direction
0：Forward
1：Reverse
LED tens digit：Stage 2 direction
0：Forward
1：Reverse
LED hundreds digit：Stage 3
direction
0：Forward
1：Reverse
LED thousands digit：Stage 4
direction
0：Forward
1：Reverse
1
0000
0709H
○
P7.10
Multi-step
speed
running
direction 2
LED single digit：Stage 5
direction
0：Forward
1：Reverse
LED tens digit：Stage 6 direction
0：Forward
1：Reverse
LED hundreds digit：Stage 7
direction
0：Forward
1：Reverse
LED thousands digit：
Reserved
1
000
070AH
○
