Eaton BACnet MS/TP OPTCJ User Manual

BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual
1-2
For more information visit: www.EatonElectrical.com
MN04012006E
August 2006
OPTCJ Board
Table 1-1: BACnet Option Board Technical Data
System Software Versions
OPTCJ BACnet option board is supported from system software versions:
●
SVX SVX00031V015 or V016.VCN
●
SPX SPX00032V011 or V012.VCN
Category Description Specification
Connections Interface OPTCJ: Pluggable connector (5.08 mm)
Data transfer method RS-485 MS/TP, half-duplex
Transfer cable Twisted pair (1 pair and shield)
Electrical isolation 500V DC
Communications BACnet MS/TP As described in ANSI/ASHRAE Standards 135-2004
Baud rate 9600, 19200 and 38400 baud
MAC Addresses 1 to 27
Environment Ambient operating
temperature
14° – 131°F (-10° – 55°C)
Storing temperature -40° – 140°F (-40° – 60°C)
Humidity <95%, No condensation allowed
Altitude Max. 3280 ft. (1000m)
Vibration 0.5 G at 9 – 200 Hz
Safety — Fulfills EN 50178 standard
