Eaton BACnet MS/TP OPTCJ User Manual

BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual
MN04012006E
For more information visit: www.EatonElectrical.com 3-3
August 2006
Annex — Protocol Implementation Conformance Statement (Normative)
(This annex is part of this Standard and is required for its use.)
BACnet Protocol Implementation Conformance Statement
Date: May 31, 2005
Vendor Name: Eaton Cutler-Hammer
Product Name: BACnet Option Board
Product Model Number: OPTCJ
Applications Software Version: 10522
Firmware Revision: 1 BACnet Protocol Revision: 4
Product Description:
BACnet Option board is designed for CH SVX family devices.
BACnet Standardized Device Profile (Annex L):
BACnet Application Specific Controller (B-ASC)
List all BACnet Interoperability Building Blocks Supported (Annex K):
DS-RP-B, DS-WP-B, DM-DDB-B, DM-DOB-B.
Segmentation Capability:
Segmented requests supported Window Size ________
Segmented responses supported Window Size ________
Standard Object Types Supported:
An object type is supported if it may be present in the device. For each standard Object Type
supported provide the following data:
1. Whether objects of this type are dynamically creatable using the CreateObject service
2. Whether objects of this type are dynamically deletable using the DeleteObject service
3. List of the optional properties supported
4. List of all properties that are writable where not otherwise required by this standard
5. List of proprietary properties and for each its property identifier, datatype, and meaning
6. List of any property range restrictions
Data Link Layer Options:
MS/TP master (Clause 9), baud rate(s): 9600, 19200, 34800
Device Address Binding:
Is static device binding supported? (This is currently necessary for two-way communication
with MS/TP slaves and certain other devices.) Yes No
Networking Options:
Router, Clause 6 — List all routing configurations, e.g., ARCNET-Ethernet, Ethernet-MS/TP, etc.
Annex H, BACnet Tunneling Router over IP
BACnet/IP Broadcast Management Device (BBMD)
Does the BBMD support registrations by Foreign Devices? Yes No
Character Sets Supported:
Indicating support for multiple character sets does not imply that they can all be supported
simultaneously.
ANSI X3.4 IBM™/Microsoft™ DBCS ISO 8859-1
ISO 10646 (UCS-2) ISO 10646 (UCS-4) JIS C 6226
If this product is a communication gateway, describe the types of non-BACnet equipment/
networks(s) that the gateway supports: __________________________________________________
