BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual
MN04012006E
For more information visit:
www.EatonElectrical.com
1-1
August 2006
Chapter 1 — General
This manual describes the installation, configuration and use of the OPTCJ BACnet fieldbus
adapter from Eaton’s electrical business. The OPTCJ is a plug-in board that is compatible
with any open or enclosed drive product that uses an SVX or SPX processor module
(including the HVX9000 or CPX9000 family). The OPTCJ adapter can be used in slots D or E of
the processor module.
BACnet is an acronym for “
B
uilding
A
utomation and
C
ontrol
N
etwork”. BACnet is a true non-
proprietary communication protocol conceived by a consortium of building management
and system users. BACnet has been adopted by ASHRAE (American Society of Heating
Refrigeration and Air-conditioning Engineers) as its standard network protocol, and is rapidly
gaining international acceptance. BACnet is used in building automation, lightning control,
air-conditioning and in heating automation. The protocol is suitable for enterprise wide
communication in large building automation projects.
The OPTCJ BACnet adapter is an MS/TP (Master-Slave/Token-Passing) device that supports
RS-485 physical layer.
WARNING
Internal components and circuit boards are at high potential when
the drive is connected to the power source. This voltage is
extremely dangerous and may cause death or severe injury if you
come into contact with it.
