BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual
MN04012006E
For more information visit: www.EatonElectrical.com 3-5
August 2006
Table 3-4: Binary Value Object
Instance
ID Object Name Description Inactive / Active
Present Value
Access Type
BV0 Ready State Indicates whether the drive is
ready or not
Not Ready / Ready R
BV1 Run/Stop State Indicates whether the drive is
running or stopped
Stop / Run R
BV2 Fwd/Rev State Indicates the rotation
direction of the motor
Fwd / Rev R
BV3 Fault State Indicates if a fault is active OK / Fault R
BV4 Warning State Indicates if a warning is active OK / Warning R
BV5 At Setpoint Ref. Frequency reached False / True R
BV6 At Zero Speed Motor Running at zero speed False / True R
BV7 General 0 Application specific bit from
drives General Status Word
0 / 1 R
BV8 General 1 Application specific bit from
drives General Status Word
0 / 1 R
BV9 General 2 Application specific bit from
drives General Status Word
0 / 1 R
BV10 General 3 Application specific bit from
drives General Status Word
0 / 1 R
BV11 General 4 Application specific bit from
drives General Status Word
0 / 1 R
BV12 General 5 Application specific bit from
drives General Status Word
0 / 1 R
BV13 General 6 Application specific bit from
drives General Status Word
0 / 1 R
BV14 General 7 Application specific bit from
drives General Status Word
0 / 1 R
BV15 Run/Stop CMD Command to start drive (FB
control is active)
Stop / Run C
BV16 Fwd/Rev CMD Command to change
rotational direction (FB
control is active)
Fwd / Rev C
BV17 Reset Fault Command to reset Active
Fault from drive
0 / Reset C
BV18 FBFixedControlWord
Bit_3
Application Specific bit from
the Fixed Control Word
0 / 1 C
BV19 FBFixedControlWord
Bit_4
Application Specific bit from
the Fixed Control Word
0 / 1 C
BV20 FBFixedControlWord
Bit_5
Application Specific bit from
the Fixed Control Word
0 / 1 C
BV21 FBFixedControlWord
Bit_6
Application Specific bit from
the Fixed Control Word
0 / 1 C
BV22 FBFixedControlWord
Bit_7
Application Specific bit from
the Fixed Control Word
0 / 1 C
BV23 FBFixedControlWord
Bit_8
Application Specific bit from
the Fixed Control Word
0 / 1 C
