Eaton BACnet MS/TP OPTCJ User Manual

BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual
3-6 For more information visit: www.EatonElectrical.com
MN04012006E
August 2006
Table 3-4: Binary Value Object (Continued)
Note: For Present Value Access Types, R = Read-only, W = Writable, C = Commandable.
Commandable values support priority arrays and relinquish defaults.
Table 3-5: Analog Value Object
Instance
ID Object Name Description Inactive/Active
Present Value
Access Type
BV24 FBFixedControlWord
Bit_9
Application Specific bit from
the Fixed Control Word
0 / 1 C
BV25 FBFixedControlWord
Bit_10
Application Specific bit from
the Fixed Control Word
0 / 1 C
BV26 FBFixedControlWord
Bit_11
Application Specific bit from
the Fixed Control Word
0 / 1 C
BV27 FBFixedControlWord
Bit_12
Application Specific bit from
the Fixed Control Word
0 / 1 C
BV28 FBFixedControlWord
Bit_13
Application Specific bit from
the Fixed Control Word
0 / 1 C
BV29 FBFixedControlWord
Bit_14
Application Specific bit from
the Fixed Control Word
0 / 1 C
BV30 FBFixedControlWord
Bit_15
Application Specific bit from
the Fixed Control Word
0 / 1 C
Instance
ID Object Name Description Units
Present Value
Access Type
AV0 Frequency Setpoint Frequency Setpoint Hz R
AV1 Output Frequency Output Frequency Hz R
AV2 Motor Speed Motor Speed Rpm R
AV3 Load (power) Motor Shaft Power Percent R
AV4 Kilowatt Hours total Megawatt Hour Counter
(Total)
kWh R
AV5 Motor Current Motor Current Amps R
AV6 DC link Voltage DC link Voltage Volts R
AV7 Motor Voltage Motor Voltage Volts R
AV8 Unit Temperature Heatsink Temperature
NOT IN SLX -series
° C R
AV9 Motor Torque In % of motor nominal Torque Percent R
AV10 Operating Days Operating Days (resettable) Day R
AV11 Operating Hours Operating Hours (resettable) Hour R
AV12 Kilowatt Hours Kilowatt Hours (resettable) kWh R
AV13 Torque Reference Torque Reference NOT IN SLX
-series
Percent R
AV14 Temperature Rise Calculated motor temperature
100,0% = nominal
temperature of motor
NOT IN SLX -series
Percent R
AV15 FBProcessDataOut1 Application specific -32768.0 to +32767.0
resolution 1.0
R
