Eaton BACnet MS/TP OPTCJ User Manual

BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual
MN04012006E
For more information visit: www.EatonElectrical.com 3-7
August 2006
Table 3-5: Analog Value Object (Continued)
Note: For Present Value Access Types, R = Read-only, W = Writable, C = Commandable.
Commandable values support priority arrays and relinquish defaults.
Instance
ID Object Name Description Units
Present Value
Access Type
AV16 FBProcessDataOut2 Application specific -32768.0 to +32767.0
resolution 1.0
R
AV17 FBProcessDataOut3 Application specific -32768.0 to +32767.0
resolution 1.0
R
AV18 FBProcessDataOut4 Application specific -32768.0 to +32767.0
resolution 1.0
R
AV19 FBProcessDataOut5 Application specific -32768.0 to +32767.0
resolution 1.0
R
AV20 FBProcessDataOut6 Application specific -32768.0 to +32767.0
resolution 1.0
R
AV21 FBProcessDataOut7 Application specific -32768.0 to +32767.0
resolution 1.0
R
AV22 FBProcessDataOut8 Application specific -32768.0 to +32767.0
resolution 1.0
R
AV23 Active Fault Code Active Fault Code — R
AV24 Speed Reference Speed Reference, percentage
of nominal speed
Percentage C
AV25 Current Limit Current Limit Amps W
AV26 Min Frequency Minimum Frequency Hz W
AV27 Maximum Frequency Maximum Frequency Hz W
AV28 Accel Time Acceleration Time seconds W
AV29 Decel Time Deceleration Time seconds W
AV30 FBProcessDataIN 1 Application specific -32768.0 to +32767.0
resolution 1.0
C
AV31 FBProcessDataIN 2 Application specific -32768.0 to +32767.0
resolution 1.0
C
AV32 FBProcessDataIN 3 Application specific -32768.0 to +32767.0
resolution 1.0
C
AV33 FBProcessDataIN 4 Application specific -32768.0 to +32767.0
resolution 1.0
C
AV34 AnyParam ID ID number that is used in
AV35
0.0 to 65535.0
resolution 1.0
W
AV35 AnyParam Value Value of ID defined by AV34 -32768.0 to +32767.0
resolution
W
