BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual
MN04012006E
For more information visit: www.EatonElectrical.com 4-1
August 2006
Chapter 4 — Fault Tracking
The table below presents the faults related to the BACnet option board. For more
information, also see your 9000X drive user manual.
The BACnet option board status LEDs have been described in more detail in Chapter 2 —
Installation.
Table 4-1: RS-485 Option Board Faults
You can define with parameters how the drive will react to certain faults:
Table 4-2: Drive Responses to Faults
Fault
Code Fault Possible Cause Correcting Measures
37 Device change Option board changed. Reset
38 Device added Option board added. Reset
39 Device removed Option board removed. Reset
40 Device unknown Unknown option board.
53 Fieldbus fault
●
The board has lost all contact with other
devices on the network.
●
Duplicate MAC ID (Bad Frames in “Comm.
status” is incremented every time a frame
is received from a device with the same
MAC ID on the same segment.)
Check the installation.
If installation is correct contact
the nearest Eaton representative.
Check that MAC ID is unique.
54 Slot fault Defective option board or slot. Check the board and slot.
Contact the nearest Eaton
representative.
Code Parameter Min Max Unit Step Default ID Note
P2.7.22 Response to
fieldbus fault
0 3 1 0 733 0 = No response
1 = Warning
2 = Fault, stop acc. to 2.4.7
3 = Fault, stop by coasting
P2.7.23 Response to slot
fault
0 3 1 0 734 0 = No response
1 = Warning
2 = Fault, stop acc. to 2.4.7
3 = Fault, stop by coasting
