Assembly and Installation
38
7. From inside the case, start the input shaft assembly into the
bearing housing bore with a soft bar. Use a soft bar and maul
to drive the shaft forward until the rear bearing seats against
the shoulder in the bore.
8. Install the drive gear on the shaft with the clutching teeth
facing towards the rear of the case.
9. Install the snap ring in the groove on the coupling shaft.
Note: If previously removed, reinstall the two PTO covers, all
plugs and the shift bar seal and scraper. Do not install
the two countershaft front bearing covers at this time.
