Assembly and Installation
44
7. Install the rear bearing housing on the rear plate with the six
retaining capscrews. The capscrew with the brass washer is
installed in the capscrew bore intersecting the speedometer
bore.
Note: The rear bearing housing may be installed with the
speedometer bore on either the left or right hand side
of the plate. Make sure that either notch in the mount-
ing surface of the housing is lined up with the oil port
in the mounting surface of the plate.
