Matrix Telecom Inverter System
52
Copyright © 2008-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-68D February 2010
AC Output
Power Capacity 1000VA/800W or 1500VA/1200W
Waveform Pure sine wave
Power factor 0.8
Nominal output voltage 110/115/120Vac or 208/220/230/240Vac
Voltage regulation Nominal ±2%
Output frequency 50/60Hz
Frequency variation Nominal ±0.5%
Frequency setting Manually, field selectable
Crest factor 3:1
THD <3% for linear load
<5% for non-linear load
Capacitive/inductive load -0.8 to +0.8 without exceeding permissible distortion for
resistive load
Efficiency Min 89% at rated load for 48Vdc System
Current limitation Electronic current limitation at overloads and short circuits.
Isolation AC-enclosure Basic isolation (Pri-Gnd) 2121Vdc/1min
Surge protection EN61000-4-5.
Telcordia GR-1089 Core ANSI C62.41-IEEE, STD 587-1980
Dynamic response <±10%, according to IEC 62040-3 class 1
Over load protection 2*I
nom
, 5s max
1.5*I
nom
, 10s max
1.25*I
nom
temperature controlled
I
nom
= 1000VA (1500VA) /output voltage
Load sharing < 5 %
Parallel Connection
Maximum number of inverter modules for parallel connection:
Without STS With STS-050 With STS-100
INV-4810 12 6 12
INV-4810E 12 12 12
INV-4815 12 4 8
INV-4815E 12 8 12
Controller Module
DC nominal voltage 48Vdc
DC voltage range 30 Vdc -72Vdc
Over current protection 2A Fuse
