Specifications
Copyright © 2008-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-68D February 2010
53
User Interface
LCD display 3-inch backlit LCD screen
4 lines by 16 characters
LED Indicators Green: Normal
Yellow: Warning
Red: Fault
Function Keys
(Enter):
(Escape):
(Up):
(Down):
Select comment, validation
Cancel
Move cursor up
Move cursor down
Buzzer Audio alarm when inverter, STS, controller module operate
abnormally
System Parameters
BaudRate Set controller serial port baud rate
Keypad tones Disable or enable keypad tones
Time & Date Set current time and date
Setting Password Set system password
Brightness Set LCD brightness
Default Change current system parameters to default values
Bat Calib Calibrate battery voltage
Environmental
Operating temperature –20°C to 70°C (-4°F to 158°F)
–5°C to 50 °C (23°F to 122°F)
full performance
Storage temperature -40°C to 85°C (-40°F to 185°F)
Operating humidity 90% Relative Humidity (non condensing)
Heat dissipation Forced air cooling for inverter/STS module
Operating Attitude 1500m
Audible noise 55dB ETS 300 753, class 3.1
Safety Standards
Inverter Module EN 60950-1 / UL-60950-1
STS Module EN 60950-1,UL-1778
Controller Module EN 60950-1
