Mechanical
Inverter Module
Dimension (D, W, H):
Weight:
270mm, 215mm, 43.8mm (10.6", 8.5", 1.7")
2.5kg (5.5 lb)
STS-050 Module
Dimension (D, W, H):
Weight:
270mm, 215mm, 43.8mm (10.6", 8.5", 1.7")
2.1kg (4.6 lb)
STS-100 Module
Dimension (D, W, H):
Weight:
270mm, 218mm, 88mm (10.6", 8.6", 3.5")
3.5kg (7.7 lb)
Controller Module
Dimension (D, W, H):
Weight:
277mm, 87.9mm, 43.5mm (10.8", 3.4", 1.7")
0.5kg (1.1 lb)
Interface Module
Dimension (D, W, H):
Weight:
79.7mm, 129.5mm, 43.5mm (3.1", 5.1", 1.7")
0.25kg (0.55 lb)
Inverter Chassis
Dimension (D, W, H):
Weight:
330mm, 483mm, 43.8mm (13", 19", 1.7")
2.7kg (6 lb)
Controller/Interface/STS-050 Chassis
Dimension (D, W, H):
Weight:
330mm, 483mm, 43.8mm (13", 19", 1.7")
2.7kg (6 lb)
Controller/Interface/STS-100 Chassis
Dimension (D, W, H):
Weight:
330mm, 483mm, 88.1mm (13", 19", 3.5")
3.5kg (7.7 lb)
MBS-050 / PD Chassis, MBS-100 / PD Chassis
Dimension (D, W, H):
Weight:
330mm, 483mm, 88mm (13", 19", 3.5")
7.0kg (15.4 lb)
