XS series operating manual
XS user manual v0.55 - 10 -
Specifications
Power supply
Mains :
115/230V~ ±15% single phase 47 to 64 Hz (DXS50/56, RXS50/56, SXS50/56, MXS500/1000).
230V~ ±15% single phase 47 to 64 Hz (DXS500/506, RXS500/506, SXS500/506).
Temporized protective fuse in mains socket on the rear panel :
RXS50/56, DXS50/56, SXS50/56, SXS16, MXS500/1000: 2AT for 230V and 4AT for 115V.
RXS500/506, DXS500/506, SXS500/506: 4AT for 230V.
Power consumption: 40VA without load, 550 VA maximum.
Operating condition
The instrument must be used indoor, in horizontal position or on tripode
Operating temperature :
Storage : -10°C to +60°C.
Operation : 0°C to +45°C.
Accuracy is rated after half an hour of warm up and for a relative humidity < 50%.
Altitude : up to 2000 meters
Max. Humidity rate: 80% for a temperature of 31°C.
Weight and dimensions
131 mm ± 0.5
440.5 mm ± 0.5
450.5 mm. ± 0.5
* Note: the weight of those units being over 18kg, 2 persons are necessary for manipulations.
Over voltage category
CAT II.
Pollution rate
Pollution 2 : Occasional conductive pollution only by condensation.
Safety class
Class I instrument : Earth protection by mains connection.
