Common queries
*STB? :
return in hexadecimal format a <NR1> which is the value of "STB". (i.e. : "#H80")
b0
0 = Interlock opened
1 = Interlock closed
b1
0 = No error
1 = Error (voltage not correct,.....)
b2
0 = End of test
1 = Test running
b3
0 = Test fail
1 = Test pass
b4
Not used
b5
Logical OR of the ESR register bits
b6
Logical OR of the STB register bits
b7
Not used
*SRE? :
return in hexadecimal format a <NR1> which is the value of "SRE". (STB register
mask)
*ESR? :
return in hexadecimal format a <NR1> which is the value of "ESR".
b0 à b3
Not used
b4
1 = Dialog error type 2 (Numerical value out of range, out of context command)
b5
1 = Dialog error type 1 (incorrect command)
b6
Not used
b7
1 = power on
NOTE : the bits are reset after the reading of the byte by the *ESR? command
*ESE? :
return in hexadecimal format a <NR1> which is the value of "ESE". (ESR register mask)
*LRN? :
This device query allows the programmer to receive a response message unit that informs
the programmer on the current device state (function's running and current test
parameters) and may be later used as program message unit elements to place the
device in the state it was.
*IDN? :
Allows the identification of the unit. The message is as follows:
<field1>,<field2>,<field3>,<field4>
field1 : Manufacturer name = Sefelec
field2 : Unit reference = CMG30, DMG50, DMG500, RMG50, MMG500, SMG50...
field3 : Serial number = 0 (not used)
field4 : Software revision = VERSION 1.60
NOTE : the *IDN? command must be used before selecting a function (from the start display)
