18 Eaton SPD Series for Mounting External to Electrical Distribution Equipment Installation Manual IM01005031E—Rev 09
AAllaarrmm SSttaattuuss – status of the alarm “Protected” or “Active Alarm Replace SPD”.
44..11..22 EEvveenntt LLoogg
Includes the follow sub-menu selections.
All events - Up to 40 events which includes surges, power up, power loss, protection reduced (%), protection
loss, and alarm silence with time and date stamps of when the event occurred are viewable to the user.
LLooww,, mmeedd aanndd hhiigghh lleevveell ssuurrggeess - Up to the last 20 date stamped events (see
13.2 Power Xpert SPD Local Display Event Log Menu Map .
44..11..33 SSeettttiinnggss
A valid user password must first be entered and confirmed before a user can access the following selections.
SSeett DDaattee aanndd TTiimmee – set the current time and date for accurate date and time stamped events. (Automatically
synced when connected to a network.) Temperature variations and other factors can affect accuracy. Also, if
the unit has been without power for an extended period of time the date and time will have to be re-entered.
SSeett DDeevviiccee NNaammee – name the device to distinguish it from other devices on your network. Device name can
be up to 20 alpha numeric characters.
SSttaarrtt DDiissppllaayy TTeesstt – cycles through the LED states and then turns on and off the LCD pixels.
CChhaannggee PPaasssswwoorrdd – changes the device password. Requires a 6-digit numeric password.
CClleeaarr SSuurrggeess && LLooggss – Clears all surge counts and event logs
SSeennssiittiivviittyy SSeettttiinngg – Increase or decrease the low surge sensitivity. It is not recommended for the user to
modify this setting without first contacting Eaton Customer Support at 1-800-809-2772 or email SPD@eaton.
com.
CCoommmmuunniiccaattiioonnss– Configure Modbus TCP, Ethernet, and IP, subnet mask, and MAC addresses. BACNet
must be configured through the web UI. See Table 12 for the Modbus register map. See Table 14 for the
BACnet register map.
44..11..44 IIddeennttiiffiiccaattiioonn
This section contains information about the device itself. It includes the following:
• Catalog number
• Style number
• Serial number
• Date code
• Firmware version
• PCB serial number
• Device name
• MAC address
• Customer support information
This information is necessary when contacting customer support concerning the device.
Power Xpert SPD Display Menu
