60 Eaton SPD Series for Mounting External to Electrical Distribution Equipment Installation Manual IM01005031E—Rev 09
TTaabbllee 1122.. PPoowweerr XXppeerrtt SSPPDD MMooddbbuuss RReeggiisstteerr MMaapp ((CCoonnttiinnuueedd))
RReeggiisstteerr NNaammee AAttttrriibbuutteess DDeessccrriippttiioonn
Range: 0 to 999999
12273
Phase C Total Surge
Counts
UINT32 RO Sum of phase C high, medium and low surge counts
Default: 0
Range: 0 to 999999
12275
DCI for Testing
Display
BOOL RW
DCI test display, LED and alarm. Setting the value starts the display
test, once the display test is complete the value will be updated to
zero by the firmware
Default: 0
Range: 0 to 1
12276
Ethernet MAC
Address
UINT8 RO NV Unique MAC address assigned to this device.(MAE)
Array size: 6 Array of 3 registers
MAC_ADDRESS()
1133..77 WWeebb UUsseerr EErrrroorr CCooddeess
TTaabbllee 1133.. WWeebb UUsseerr EErrrroorr CCooddeess
EErrrroorr MMeessssaaggee DDeessccrriippttiioonn AAccttiioonn RReeqquuiirreedd
Login Failed (Login Page)
User not authorized to access device Contact administrator for
authorization
One Admin Role is mandatory in System
User Self-Deletion Not Permitted Contact administrator to
delete user
Username Already Exists Username already exists on the device Create unique username
User Database Full
Password Security Violation
Password Matches With Name or Existing
Password
Username and password match Create unique username
and password
User Locked Temporarily Too many users trying to access device
HTTP Version Not Supported
Failed to Fetch
Device communication failed (login page), device
communication failure (firmware update page)
Codepack integrity check has failed Image in the codepack file is corrupt Re-install firmware
Codepack integrity check has aborted firmware
update
Displayed when any one image is corrupt during
multiple firmware update
Re-install firmware
Final integrity check is invalid Multiple reasons
