Eaton SPD Series for Mounting External to Electrical Distribution Equipment Installation Manual IM01005031E—Rev 09 61
1133..88 BBAACCnneett RReeggiisstteerr MMaapp
TTaabbllee 1144.. BBAACCnneett MMaapp -- AAnnaalloogg OObbjjeeccttss
AAnnaalloogg OObbjjeeccttss
IInnssttaannccee
OObbjjeecctt NNaammee OObbjjeecctt DDeessccrriippttiioonn
OObbjjeecctt
TTyyppee
UUnniitt
AAcccceessss
TTyyppee
CCOOVV
IInnccrreemmeenntt
0
Sensitivity Surge sensitivity AV No unit R/W
1
1
Phase A High Surge Count
Phase A high surge count AV No unit
RO
1
2
Phase A Medium Surge Count Phase A medium surge
count
AV No unit RO
1
3
Phase A Low Surge Count Phase A low surge count AV No unit RO
1
4
Phase B High Surge Count Phase B high surge count AV No unit RO
1
5
Phase B Medium Surge Count
Phase B medium surge
count
AV No unit
RO
1
6
Phase B Low Surge Count Phase B low surge count AV No unit RO
1
7
Phase C High Surge Count Phase C high surge count AV No unit RO
1
8
Phase C Medium Surge Count Phase C medium surge
count
AV No unit RO
1
9
Phase C Low Surge Count Phase C low surge count
AV No unit
RO
1
10 Phase A % Protection Percentage of protection
available on phase A
AV No unit RO
1
11
Phase B % Protection Percentage of protection
available on phase B
AV No unit RO
1
12
Phase C % Protection Percentage of protection
available on phase C
AV No unit RO
1
13
Phase N-G % Protection Percentage of protection
available on NG
AV No unit RO
1
14
Phase A Total Surge Counts
Phase A total surge
counts
AV No unit
RO
1
15
Phase B Total Surge Counts Phase B total surge
counts
AV No unit RO
1
16
Phase C Total Surge Counts Phase C total surge
counts
AV No unit RO
1
17
RTC Time RTC time AV No unit RO
1
18
Set Time Set time AV No unit R/W
1
19
Total Low Surge Counts Total low surge counts AV No unit RO
1
20
Total Medium Surge Counts Total medium surge
counts
AV No unit RO
1
21
Total High Surge Counts
Total high surge counts AV No unit
RO
1
Appendix
