62 Eaton SPD Series for Mounting External to Electrical Distribution Equipment Installation Manual IM01005031E—Rev 09
TTaabbllee 1144.. BBAACCnneett MMaapp -- AAnnaalloogg OObbjjeeccttss ((CCoonnttiinnuueedd))
AAnnaalloogg OObbjjeeccttss
IInnssttaannccee
OObbjjeecctt NNaammee OObbjjeecctt DDeessccrriippttiioonn
OObbjjeecctt
TTyyppee
UUnniitt
AAcccceessss
TTyyppee
CCOOVV
IInnccrreemmeenntt
22
Total Surge Counts Total surge counts AV No unit RO
1
23
System Faults System faults AV No unit RO
1
24
Method of IP Allocation Allows to set the method
used to allocate an IP
address
AV No unit R/W
1
TTaabbllee 1155.. BBAACCnneett MMaapp -- BBiinnaarryy OObbjjeeccttss
BBiinnaarryy oobbjjeeccttss
IInnssttaannccee
OObbjjeecctt NNaammee OObbjjeecctt DDeessccrriippttiioonn
OObbjjeecctt
TTyyppee
IInnaaccttiivvee
TTeexxtt
AAccttiivvee TTeexxtt AAcccceessss
TTyyppee
0
Clear Surge Log Events Clear surge log events
BV
OFF ON
R/W
1
Clear Surge Counts Clear surge counts BV OFF ON R/W
2
Phase A Green Led Status Phase A green led status BV OFF ON RO
3
Phase A Yellow Led Status Phase A yellow led status BV OFF ON RO
4
Phase A Red Led Status Phase A red led status BV OFF ON RO
5
Phase B Green Led Status
Phase B green led status BV
OFF ON RO
6
Phase B Yellow Led Status Phase B yellow led status BV OFF ON RO
7
Phase B Red Led Status Phase B red led status BV OFF ON RO
8
Phase C Green Led Status Phase C green led status
BV
OFF ON RO
9
Phase C Yellow Led Status Phase C yellow led status BV OFF ON RO
10
Phase C Red Led Status Phase C red led status BV OFF ON RO
11
NG Green Led Status NG green led status BV OFF ON RO
12
NG Yellow Led Status NG yellow led status
BV
OFF ON RO
13
NG Red Led Status NG red led status BV OFF ON RO
14
Alarm status Alarm status BV Protected Protection
loss
RO
15
Silences Alarm Silences the alarm BV Silence? Silenced R/W
16
Clear General Log Clear general log
BV
OFF ON
R/W
AV = Analog Value BV = Binary Value
Appendix
