Eaton SPD Series Installation Manual

Eaton SPD Series for Mounting External to Electrical Distribution Equipment Installation Manual IM01005031E—Rev 09 45
CChhaapptteerr 1100 SSppeecciiffiiccaattiioonnss
TTaabbllee 55.. SSppeecciiffiiccaattiioonnss
DDeessccrriippttiioonn CCaattaalloogg NNoo..
Surge current capacity per phase
50, 80, 100, 120, 160, 200, 250, 300, 400 kA ratings available
Nominal discharge current (In)
20kA
Short circuit current rating (SCCR)
200kA
SPD type Basic feature package = type 1 (can also be used in type 2 applications)
Standard, Standard with Surge Counter, and Power Xpert SPD feature
packages = type 2
Enclosure Types
NEMA 1, NEMA 4, NEMA 4X (304 SST) (Power Xpert SPD not available in
NEMA 4X)
Standard split phase voltages available 120/240
Single phase
230
Three phase wye system voltages available 120/208, 127/220, 230/400, 277/480, 347/600
Three phase delta system voltages 240, 480, 600
Three phase high leg delta system voltages 120/240
Phase wire length 48” of 10AWG extend beyond the conduit hub
Relay wire length (optional) 48” of 14AWG extend beyond the conduit hub
RoHS compliant Yes
Internal disconnect (optional) Eaton 30 Amp FDC circuit breaker, type MCCB
Input power frequency 50/60 Hz, Power Xpert SPD
Power consumption (Basic units)
208Y, 220Y, 230L, 240S, 240D, and 240H voltage codes 0.5 W
400Y and 480Y and 480D voltage codes 1.1 W
600Y and 600D voltage codes 1.3 W
Power consumption (Standard with Surge Counter units)
208Y, 220Y, 230L, 240S, 240D, and 240H voltage codes 0.6 W
400Y and 480Y and 480D voltage codes 1.7 W
600Y and 600D voltage codes 2.1 W
Power consumption (Power Xpert SPD units)
208Y, 220Y, 230L, 240S, 240D, and 240H voltage codes
4 W
400Y, 480Y, and 480D voltage codes 4 W
600Y and 600D voltage codes 4 W
Phase Protection Single split phase L-N, L-G, N-G, L-L
Single phase L-N, L-G, N-G
Three phase wye L-N, L-G, N-G, L-L
Three phase delta L-G, L-L
Three phase high leg delta L-N, L-G, N-G, L-L, H-N, H-G, H-L
Maximum Continuous Operating Voltage (MCOV)
208Y, 220Y, 240S voltage codes
230L,
240H
400 and 480Y voltage codes 600Y
150 L-N, 300 L-G, 150 N-G, 300 L-L
320 L-N, 640 L-G, 320 N-G
150 L-N, 300 L-G, 150 N-G, 300 L-L, 320 H-N, 470 H-G, 470 H-L
320 L-N, 640 L-G, 320 N-G, 640 L-L

Eaton SPD Series Specifications

General

Type	Surge Protective Device
Voltage Rating	120/240V, 208Y/120V, 480Y/277V
Surge Current Capacity	Up to 200kA
Modes of Protection	L-N, L-G, N-G
Operating Frequency	50/60Hz
Certifications	UL 1449
SPD Type	Type 1, Type 2
Maximum Surge Current	Up to 200kA
Nominal Discharge Current (In)	10kA, 20kA
Short Circuit Current Rating (SCCR)	Up to 200kA
Enclosure Type	NEMA 1
Mounting	Panel Mount
Standards	UL 1449, IEEE C62.41
Diagnostics	Visual Indicators
Remote Monitoring	Optional
Maximum Discharge Current (Imax)	Up to 200kA
