46 Eaton SPD Series for Mounting External to Electrical Distribution Equipment Installation Manual IM01005031E—Rev 09
TTaabbllee 55.. SSppeecciiffiiccaattiioonnss ((CCoonnttiinnuueedd))
DDeessccrriippttiioonn CCaattaalloogg NNoo..
600Y voltage code
240D voltage code
480D voltage code
600D voltage code
420 L-N, 420 L-G, 420 N-G, 840 L-L
300L- L-G, 300 L-L
640 L-G, 640 L-L
840 L-G, 840 L-L
Ports
1
Operating temperature -40° C to 50° C (-40 F to 122° F),
Power Xpert Surge protection (-40° C to 50° C),
Power Xpert LCD module (-20° C to 70° C)
Operating humidity 5% through 95%, non-condensing
Operating altitude Up to 16,000 ft (5000 m) Power Xpert SPD up to 6561 ft (2000 m)
Weight Reference Figure 3- Figure 7.
Form C relay contact ratings 150 Vac at 0.46 A, 30 Vdc at 1 A, terminal block connector rated 300 V, 16
A suitable for use with 30-12 AWG solid or stranded copper wire. Torque
5-7 lbs-in.
Form C relay contact logic Power on, normal state - NO contact = OPEN, NC contact = CLOSED Power
off, fault state, - NO contact = CLOSED, NC contact = OPEN
Form C relay contact logic Power on, normal state - NO contact = OPEN, NC contact = CLOSED Power
off, fault state, - NO contact = CLOSED, NC contact = OPEN
Real time clock accuracy, Power Xpert SPD synchronized when connected to a network via an Ethernet cable, +/- 2
min/month @ 25°C when not connected to a network
EMI/RFI filtering attenuation (Standard and Standard with
Surge Counter and Power Xpert SPD)
Up to 50 dB from 10 kHz to 100 MHz
Ethernet port Data rate 100/10 Mbps, wire type: equal or exceed 5 UTP category 5, use
of STP (shielded twisted pair) will improve EMI performance. Connector
type: RJ45 modular, ground metal shield
Agency certifications and approvals Feature packages 1, 2,
and 3
UL 1449 5th Edition listed, UL 1283 7th Edition (type 2 SPDs only) IEC
61643-11/EN 61643-11, Part 11: Test Class II. See Section 11.0 Ordering
guidelines for specific models.
Agency certifications and approvals Feature package 4
(Power Xpert SPD)
cULus certified, UL1449 5th Edition listed, UL1283 7th Edition IEC 61643-
11/EN 61643-11, Part 11: Test Class II. See Section 11.0 Ordering
guidelines for specific models.
Warranty 10 years, 15 years if you register on www.eaton.com/spd and then click
the warranty registration icon..
ROHS compliant Yes
Wire length and AWG Factory prewired with 48 inches of #10 AWG wire.
