General| Type | Surge Protective Device |
|---|---|
| Voltage Rating | 120/240V, 208Y/120V, 480Y/277V |
| Surge Current Capacity | Up to 200kA |
| Modes of Protection | L-N, L-G, N-G |
| Operating Frequency | 50/60Hz |
| Certifications | UL 1449 |
| SPD Type | Type 1, Type 2 |
| Maximum Surge Current | Up to 200kA |
| Nominal Discharge Current (In) | 10kA, 20kA |
| Short Circuit Current Rating (SCCR) | Up to 200kA |
| Enclosure Type | NEMA 1 |
| Mounting | Panel Mount |
| Standards | UL 1449, IEEE C62.41 |
| Diagnostics | Visual Indicators |
| Remote Monitoring | Optional |
| Maximum Discharge Current (Imax) | Up to 200kA |
