EBO KT-LCD3 - Preface; Outlook and Size

PREFACE
This manual aims to help the user understand and familiarize themselves with the KT-LCD3
functions, operation, setting the e-bike Parameters, how to achieve the best match of the e-
bike components to improve performance of the electric bike system. The manual covers
installation, operation, parameter setting of the LCD and how to use it properly, which help
user setup the functionality of the electric bike system.
OUTLOOK AND SIZE
LCD Dimension (mm)
Dual Bracket Mounting Dimension (mm)
4
86
58
30
65
96
20
14
12
