MAINTENANCE
 Push the oil separator hose onto the valve cover.
STEP 9 – EXHAUST GAS COMPENSATOR & HOSE CLAMPS
 Loosen the hose clamps on the exhaust gas compensator by a hose clamp
pliers and put them aside.
 Remove the exhaust gas compensator together with the two hose clamps
from both ends of the pipe.
 Replace the exhaust gas compensator including the two hose clamps and
fix the exhaust gas compensator with the 2 hose clamps by a hose clamp
pliers.
STEP 10 – OIL
 Add oil to the engine. Fill a maximum of 40 litres of oil through the filler neck.
Use a funnel to fill the engine.
 Check the oil level on the dipstick to ensure that the engine is not overfilled.
To do this, briefly screw on the oil cover and then take it off again.
 After checking the oil level, fasten the oil cap by a water pump pliers.
Fig. 4.35
Fig. 4.36
Fig. 4.37
Fig. 4.38
Fig. 4.39
Fig. 4.40
13
