MAINTENANCE
STEP 9 – EXHAUST GAS COMPENSATOR & HOSE CLAMPS
Loosen the 2 hose clamps on the exhaust gas compensator by a hose clamp
pliers and put them aside.
Remove the exhaust gas compensator together with the 2 hose clamps from
both ends of the pipe.
Replace the exhaust gas compensator including the 2 hose clamps and fix
the exhaust gas compensator with the 2 hose clamps by a hose clamp pliers.
STEP 10 – LAMBDA SENSOR
Separate the lambda sensor cable from the cable tree at the plug-in contact.
Unscrew the old lambda sensor from its socket by a lambda sensor top long
and screw in the new lambda sensor.
Reconnect the Lambda sensor cable to the cable tree.
Fig. 7.26
Fig. 7.27
Fig. 7.28 Fig. 7.29
