MAINTENANCE
Only perform maintenance work on the XRGI
®
system when it is not in
operation and is fully cooled down! Otherwise, there is a risk of burns from
hot components and/or scalding if substances should escape.
REQUI
RED MATERIAL
EC POWER service kit for XRGI
®
15 (Item No.: 01KIT2503) consisting of:
 1 pc. air filter
 3 pcs. engine oil
 1 pc. plug for measuring point
 4 pcs. spark plugs
 1 pc. oil filter
REQUIRED TOOLS
 Oil suction pump  Torque wrench
 Oil filter spanner  17 mm socket insert
 Water pump pliers  20.8 mm spark plug wrench
 Funnel  3 mm Allen screwdriver
 feeler gauge  5 mm Allen screwdriver
 FS2009USB programming device  17 mm open-ended spanner
 Flue gas analyser
Before commencing maintenance work, shut down the XRGI
®
system at
the user level on the iQ-Control Panel and at the main switch. Close the
gas valve and unplug the Q-Heat Distributor.
6. MAINTENANCE XRGI® 15
Fig. 6.01
