KOSMOS User Guide 59
Annotating images and clips
2. Tap the exam row that you want to edit.
3. Tap the clip you want to annotate.
4. Tap the Edit icon.
From the Patient screen:
1. Tap a patient from the list.
2. Tap the exam.
3. Tap the image/clip you want to annotate.
4. Tap the Edit icon.
Annotation tools
Annotations can be added to individual images and clips.
When you add an annotation (text, measurements, arrow, area) to a clip or a cine,
they persist through all frames.
You can also hide the overlay of the annotations you make by tapping the Hide
overlay icon on saved images and clips.
Measuring with the caliper tool
When a caliper is not selected and you start dragging one of the two end points
of the caliper, the caliper will become selected and will resize based on where
you are dragging it.
To place a measurement:
1. From the Edit image or Edit clip screen, tap DISTANCE, and a caliper appears
in the center of the image or clip.
2. Tap to select the caliper.
3. To resize the caliper, tap and drag one of its endpoints.
4. To move the caliper, tap anywhere on the caliper except the two end points.
Notice that the distance of the caliper displays in the legend on the upper
left side of the screen. If you have multiple calipers, they display in
different colors.
