Page #138 background imageLoading...
Page #138 background image
138
Specifications
<GENERAL>
Power Supply 14.4V DC (11-16V)
Current Drain 3A MAX
Dimensions (W x H x D)
In-Dash Unit 7" x 2" x 6-1/8" (178 x 50 x 155mm)
Mass (weight) Approx. 1.4kg
Usage temperature range -20°C to +65°C (-4°F to +149°F )
Storage temperature range -40°C to +85°C (-40°F to +185°F )
<FM TUNER>
Frequency Range
USA: 87.75~107.9MHz (0.2MHz step)
Asia/Australia: 87.5~108MHz (0.05MHz step)
Usable Sensitivity 13dBf
Frequency Response 30~15,000Hz, 3dB
Stereo Separation 38dB
<AM TUNER>
Frequency Range
USA: 530~1,710kHz (10kHz step)
Asia/Australia: 522~1,629kHz (9kHz step)
Usable Sensitivity 20µV
<CD SECTION>
Frequency Response 20~20,000Hz, 3dB
Wow & Flutter Below measurable limits
Stereo Separation 85dB
S/N Ratio (A-weighted) 100dB
Dynamic Range 98dB
Total Harmonic Distortion 0.006%
<AUDIO AMPLIFIER>
Power Output 13W x 4 (20~20,000Hz, 0.8% THD,
4 ) Max. 50W x 4
Output Level/Impedance 5V (0dB CD)
55 line-out impedance
Tone Action Bass: 12dB at 63/100Hz
Treble: 12dB at 8k/10kHz
Loudness +10dB at 100Hz/+6dB at 10kHz
Specifications
