Eclipse Rotary Actuator Instruction Manual 904-7/24/06
16
Once the front coverplate is removed, the terminal
strip on the left side (P2) is used for the power supply,
and low and high re auxiliary contacts. The terminal
strip on the right side (P1) is used for the control
signal inputs (4-20mA, 0-10V, etc.).
To install a wire into a terminal, rst be sure the ter-
minal is full open. Strip the wire insulation back 1/4"
(6mm), and insert the wire. Hold the wire in place
while tightening the terminal screw. Inspect the
wire for loose strands and gently pull it to ensure a
secure connection. Use only one wire per terminal.
Figure 3 on page 18 shows the wiring diagram for
the actuator, while Figure 4 on page 19 shows a typi-
cal application.
Connect the ground wire to P2-G, the neutral
conductor to P2-1, and the “hot” or line voltage
conductor to P2-2. Provide proper circuit protec-
tion (fuse or circuit breaker).
The internal contacts are isolated and voltage-free.
Take care not to exceed the contact ratings listed in
the specications table on page 30. These contacts can
be used for position detection. Connect an external
supply to the common terminals, P2-3 and P2-5.
Connect the external low position load to P2-6, and
the external high position load to P2-4.
A switch or voltage-free contact can be wired
between P1-5 (Low Fire) and P1-1 (COM) to
move the actuator to the low re position.
Power Supply
Auxiliary Contacts
Low Fire Wiring
Warning:
After wiring, inspect the seal and install
the cover carefully. Make sure cover is
seated properly to seal out water.
