PARAMETER DESCRIPTION
Power Supply 120VAC (+10%, -15%), 50/60 Hz or 230VAC (+10%, -15%), 50/60 Hz
Internal power consumption: 5VA
Operating Temperature
-
20 to +60 °C (0 to 140 °F)
Storage Temperature
-
25 to +65 °C (-10 to 150 °F)
Humidity 5-95% RH noncondensing
Inputs, Analog 4
-
20mA @ 250Ω impedance; 0-10Vdc @ 200KΩ Impedance
Inputs, Digital (Isolated contacts) Force to high position; force to low position; disable setting codes
Shaft Rotation Adjustable, 0 to 90º maximum.
Minimum Step 1°
Shaft Rotation Direction Selectable: clockwise or counterclockwise
Keypad Orientation Four positions
Display Accuracy ± 1.5°
Position Indicator 9/16" high LED, 0
to
90°
Speed 13 seconds nominal for 90° @ 60Hz
2.3 N-m (20 lb-in)
3.9 N-m (35 lb-in) @ stall
Auxiliary Contact Ratings
Resistive Load: 8A
Inductive Load: 2A
Wiring Connectors Flexible cord connector: 5.8 to 10 mm ( 0.231to 0.394 in.) OD cable
3/8 in. liquid tight conduit
1/2 in. Female NPT adapter
Terminal Connections 0.5 - 1.5 mm
2
(22 - 16 AWG)
Shipping Weight
1.1 kg (2.5 lb.)
Environment NEMA 4
Torque (Stall Protected)
